K8s 集群插件实战：CNI / CoreDNS / Metrics / Dashboard 完整部署

写于 2021-09，背景：K8s 1.22 时代，Calico 3.22、CoreDNS 1.8、metrics-server 0.6、Dashboard v2.5 稳定。本文基于二进制部署的 K8s 集群，补齐 4 大必装插件。

一、插件全景

K8s 装好 master 三大组件（apiserver / scheduler / controller-manager）后，还不能跑业务。还差 4 类插件：

类别	作用	必装？
CNI（网络）	Pod 之间跨节点通信	必装
DNS	Service 域名解析（coredns）	必装
Metrics	Pod/Node 资源指标（kubectl top）	强烈推荐
Dashboard	Web UI	按需

二、CNI：Calico 网络插件

Calico 是 K8s 生态最流行的 CNI 之一，纯 L3 路由（无需 iptables 桥接），性能好，支持 NetworkPolicy。

2.1 下载

1
mkdir -p /k8s/calico/config && cd /k8s/calico/config

2.2 tigera-operator.yaml

1
2
3
4
kubectl create -f https://raw.githubusercontent.com/projectcalico/calico/v3.26.1/manifests/tigera-operator.yaml

# 验证
kubectl get pods -n tigera-operator

2.3 custom-resources.yaml

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
cat > /k8s/calico/config/custom-resources.yaml << 'EOF'
# This section includes base Calico installation configuration.
apiVersion: operator.tigera.io/v1
kind: Installation
metadata:
  name: default
spec:
  # Configures Calico networking.
  calicoNetwork:
    # Note: the ipPools section cannot be modified post-install.
    ipPools:
      - blockSize: 26
        cidr: 172.218.0.0/16  # 与 kube-apiserver 的 --service-cluster-ip-range 不冲突
        encapsulation: VXLANCrossSubnet
        natOutgoing: Enabled
        nodeSelector: all()

---
# This section configures the Calico API server.
apiVersion: operator.tigera.io/v1
kind: APIServer
metadata:
  name: default
spec: {}
EOF

kubectl create -f /k8s/calico/config/custom-resources.yaml

# 验证
kubectl get pods -n calico-system
# NAME                                       READY   STATUS    RESTARTS   AGE
# calico-kube-controllers-7ddc4f45bc-6vwhr   1/1     Running   0          2m26s
# calico-node-2sq7m                          1/1     Running   0          2m26s
# calico-node-9jt4c                          1/1     Running   0          2m26s
# calico-node-znjtn                          1/1     Running   0          2m26s

2.4 替代部署方式：calico.yaml

如果不想用 operator，也可以直接 apply 大 YAML：

1
2
3
4
5
6
7
8
9
wget https://raw.githubusercontent.com/projectcalico/calico/v3.26.1/manifests/calico.yaml

# 修改 Pod CIDR
sed -i 's|192.168.0.0/16|172.218.0.0/16|g' calico.yaml
# 或者编辑文件：
#   - name: CALICO_IPV4POOL_CIDR
#     value: "172.218.0.0/16"

kubectl apply -f calico.yaml

2.5 卸载 Calico

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
# 1. 删除 K8s 资源
kubectl delete -f calico.yaml

# 2. 检查残留（tunl0 接口）
ip addr show | grep tunl
modprobe -r ipip

# 3. 清理本地 CNI 文件
rm -rf /etc/cni/net.d/*
rm -rf /opt/cni/bin/*
rm -rf /var/lib/cni/*

# 4. 重启 kubelet
systemctl restart kubelet

三、CoreDNS：集群 DNS

K8s Service 通过域名访问（如 mysql.default.svc.cluster.local），依赖 CoreDNS 提供解析。

3.1 方式一：Helm 安装（推荐）

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
# 装 helm（如未装）
wget https://get.helm.sh/helm-v3.13.3-linux-amd64.tar.gz
tar xvf helm-v3.13.3-linux-amd64.tar.gz
sudo cp linux-amd64/helm /usr/local/bin/

# 添加 chart 仓库
helm repo add coredns https://coredns.github.io/helm
helm repo update

# 拉 chart
helm pull coredns/coredns
tar xvf coredns-*.tgz

# 修改 values.yaml
# 1. 改 clusterIP（必须与 kube-apiserver 的 service-cluster-ip-range 在同段）
sed -i 's|clusterIP:|clusterIP: "10.96.0.10"|' coredns/values.yaml
# 默认的 10.96.0.10 即可

# 2. 改镜像源到阿里云（避免拉 registry.k8s.io 超时）
sed -i "s#registry.k8s.io/#registry.aliyuncs.com/google_containers/#g" coredns/values.yaml

# 安装
helm install coredns ./coredns/ -n kube-system

# 验证
kubectl get pods -n kube-system -l k8s-app=kube-dns

3.2 方式二：kubectl apply 原生 YAML

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
# 下载基础 manifest
wget https://raw.githubusercontent.com/kubernetes/kubernetes/v1.28.5/cluster/addons/dns/coredns/coredns.yaml.base

# 替换占位符
sed -i 's|__DNS__DOMAIN__|cluster.local|g' coredns.yaml.base
sed -i 's|__DNS__MEMORY__LIMIT__|150Mi|g' coredns.yaml.base
sed -i 's|__DNS__SERVER__|10.96.0.10|g' coredns.yaml.base
sed -i 's|__DNS__IMAGE__|registry.aliyuncs.com/google_containers/coredns:v1.10.1|g' coredns.yaml.base

mv coredns.yaml.base coredns.yaml
kubectl apply -f coredns.yaml

3.3 验证 DNS

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
# 跑一个 busybox 测试
kubectl run -it --rm --restart=Never --image=infoblox/dnstools:latest dnstools

# 解析 kubernetes
/ # host kubernetes
# kubernetes.default.svc.cluster.local has address 10.96.0.1

# 跨 namespace 解析
/ # host coredns.kube-system
# coredns.kube-system.svc.cluster.local has address 10.96.0.10

3.4 常见错误：CrashLoopBackOff

1
2
3
# 查看日志
kubectl logs -n kube-system coredns-687c56b785-fz2mx
# "loop" error: 127.0.0.53 in /etc/resolv.conf

根因：Ubuntu 22.04 默认启用 systemd-resolved（监听 127.0.0.53:53），CoreDNS 转发时形成循环。

解决：

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
sudo apt install -y unbound
sudo systemctl stop systemd-resolved
sudo systemctl disable systemd-resolved
sudo rm -rf /etc/resolv.conf
sudo touch /etc/resolv.conf
echo "nameserver 8.8.8.8" | sudo tee /etc/resolv.conf

# 重启 docker 和 kubelet
sudo systemctl restart docker
sudo systemctl restart kubelet

四、Metrics Server：资源指标

kubectl top node / kubectl top pod 依赖 metrics-server 采集的指标。HPA（自动扩缩容）也用它。

4.1 单机版

1
kubectl apply -f https://github.com/kubernetes-sigs/metrics-server/releases/download/v0.6.4/components.yaml

4.2 高可用版

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
mkdir -p /k8s/metrics-server && cd /k8s/metrics-server
wget https://github.com/kubernetes-sigs/metrics-server/releases/download/v0.6.4/high-availability.yaml

# 关键修改（必须做）：

# 1. 镜像地址改阿里云
sed -i "s#registry.k8s.io/metrics-server#registry.cn-hangzhou.aliyuncs.com/google_containers#g" high-availability.yaml

# 2. 加 --kubelet-insecure-tls（自签证书场景）
# 编辑 high-availability.yaml，找到 args 段，加入：
#   - --kubelet-insecure-tls

# 3. 1.25+ 改 PodDisruptionBudget apiVersion
sed -i 's|policy/v1beta1|policy/v1|g' high-availability.yaml

# 部署
kubectl apply -f /k8s/metrics-server/high-availability.yaml

4.3 验证

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
# 等 1~2 分钟
kubectl top node
# NAME      CPU(cores)   CPU%   MEMORY(bytes)   MEMORY%
# master1   170m         4%    1706Mi          45%
# master2   186m         4%    1669Mi          44%
# master3   148m         3%    1641Mi          43%

kubectl top pod -A
# NAMESPACE     NAME                                       CPU(cores)   MEMORY(bytes)
# kube-system   calico-kube-controllers-7ddc4f45bc-6vwhr   6m           55Mi
# kube-system   coredns-687c56b785-fz2mx                   2m           57Mi

4.4 常见错误

报错 “x509: certificate signed by unknown authority”：

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
# 编辑 high-availability.yaml，给 metrics-server 挂载 CA
spec:
  template:
    spec:
      containers:
      - args:
        - --cert-dir=/tmp
        - --secure-port=4443
        - --kubelet-preferred-address-types=InternalIP,ExternalIP,Hostname
        - --kubelet-use-node-status-port
        - --kubelet-insecure-tls   # ← 必须
        - --metric-resolution=15s
        image: registry.cn-hangzhou.aliyuncs.com/google_containers/metrics-server:v0.6.4
        volumeMounts:
        - mountPath: /tmp
          name: tmp-dir
        - mountPath: /etc/kubernetes/pki
          name: ca-ssl
      volumes:
      - emptyDir: {}
        name: tmp-dir
      - name: ca-ssl
        hostPath:
          path: /etc/kubernetes/pki

五、Dashboard：Web UI

K8s 官方 Dashboard，提供 Web 控制台。v2.7+ 默认 token 鉴权。

5.1 部署

1
kubectl apply -f https://raw.githubusercontent.com/kubernetes/dashboard/v2.7.0/aio/deploy/recommended.yaml

5.2 暴露 NodePort（默认只 ClusterIP）

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
# 编辑 Service
kubectl edit svc kubernetes-dashboard -n kubernetes-dashboard

# 改 type: ClusterIP → type: NodePort
# ports 段加 nodePort: 32443
spec:
  type: NodePort
  ports:
    - port: 443
      targetPort: 8443
      nodePort: 32443

5.3 创建 admin 用户

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
cat > /k8s/dashboard/dashboard-user.yaml << 'EOF'
apiVersion: v1
kind: ServiceAccount
metadata:
  name: admin-user
  namespace: kube-system
---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: admin-user
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: cluster-admin
subjects:
- kind: ServiceAccount
  name: admin-user
  namespace: kube-system
EOF

kubectl apply -f /k8s/dashboard/dashboard-user.yaml

5.4 生成登录 Token

1
2
3
4
5
6
7
# K8s 1.24+ 用 create token
kubectl -n kube-system create token admin-user
# 把输出复制，登录时粘贴

# K8s 1.23 及以下用 secret
kubectl -n kube-system get secret | grep admin-user
kubectl -n kube-system describe secret <SECRET_NAME>

5.5 登录

浏览器访问：

1
https://192.168.139.150:32443/

选 “Token”，粘贴上面生成的 token。

六、验证集群完整功能

装完 4 大插件后，跑一遍"集群健康度"自检：

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
# 1. 节点全部 Ready
kubectl get nodes
# NAME      STATUS   ROLES           AGE   VERSION
# master1   Ready    control-plane   1d    v1.28.5
# master2   Ready    control-plane   1d    v1.28.5
# master3   Ready    control-plane   1d    v1.28.5
# worker1   Ready    <none>          1d    v1.28.5
# worker2   Ready    <none>          1d    v1.28.5

# 2. Pod 全部 Running
kubectl get pods -A

# 3. 部署测试
cat <<EOF | kubectl apply -f -
apiVersion: v1
kind: Pod
metadata:
  name: busybox
  namespace: default
spec:
  containers:
  - name: busybox
    image: busybox:1.36
    command: ["sleep", "3600"]
EOF

# 4. DNS 解析
kubectl exec busybox -n default -- nslookup kubernetes
# Server:    10.96.0.10
# Address 1: 10.96.0.10 kube-dns.kube-system.svc.cluster.local
# Name:      kubernetes
# Address 1: 10.96.0.1 kubernetes.default.svc.cluster.local

# 5. 跨 namespace 解析
kubectl exec busybox -n default -- nslookup coredns.kube-system
# 应该返回 10.96.0.10

# 6. 资源指标
kubectl top node
kubectl top pod -A

# 7. 部署 Nginx 三副本
cat <<EOF | kubectl apply -f -
apiVersion: apps/v1
kind: Deployment
metadata:
  name: nginx-deployment
spec:
  replicas: 3
  selector:
    matchLabels:
      app: nginx
  template:
    metadata:
      labels:
        app: nginx
    spec:
      containers:
      - name: nginx
        image: nginx
        ports:
        - containerPort: 80
EOF

# 看副本是否跨节点
kubectl get pod -o wide
# NAME                                READY   STATUS    IP                NODE
# nginx-deployment-7c5ddbdf54-7dmkk   1/1     Running   172.218.136.5    master3
# nginx-deployment-7c5ddbdf54-dwxt7   1/1     Running   172.218.137.68   master1
# nginx-deployment-7c5ddbdf54-dxdpm   1/1     Running   172.218.180.6    master2

# 清理
kubectl delete deployment nginx-deployment
kubectl delete pod busybox

七、常见坑

CNI Pod CIDR 与 service-cluster-ip-range 重叠：Calico 报 “ip pool in use” 错误
CoreDNS CrashLoopBackOff：/etc/resolv.conf 有 127.0.0.53，停 systemd-resolved
metrics-server 报 x509：加 --kubelet-insecure-tls 或挂载 /etc/kubernetes/pki
Dashboard 登录 401：1.24+ 改用 kubectl create token，1.23 及以下用 secret
Dashboard 看不到 namespace：ServiceAccount 没绑 cluster-admin

八、前置知识 / 下一步

前置：

Master 三大组件（参考 2020-12-15《K8s Master 三大组件》）
K8s 网络原理（Service CIDR、Pod CIDR）

下一步：

K8s 集群管理（2021-12-15）—— 升级、节点隔离
K8s 资源限制与探针（2022-03-15）—— Pod 调优
Kubeadm 一键部署（2022-06-15）—— 生产部署实战
