etcd 3.5 集群二进制部署与 TLS 证书签发

为什么 etcd 必须独立部署

etcd 是 K8s 唯一的状态存储后端，所有 Pod/Service/ConfigMap 状态都写在 etcd 里。生产环境对 etcd 的要求：

3 节点或 5 节点集群（raft 多数派容错）
所有通信必须 TLS（peer + client）
必须与 kube-apiserver 分开部署（不要复用 master 节点或用容器化 etcd）

本文用 cfssl 工具签发全套证书，部署 3 节点 etcd 集群。

适用版本：etcd v3.5.11 / cfssl 1.6.4 / Ubuntu 22.04 部署位置：master1、master2、master3 各一份

1. 安装 cfssl 工具

1
2
3
4
5
6
7
8
cd /data/softs
cp cfssl_1.6.4_linux_amd64 /usr/local/bin/cfssl
cp cfssljson_1.6.4_linux_amd64 /usr/local/bin/cfssljson
cp cfssl-certinfo_1.6.4_linux_amd64 /usr/local/bin/cfssl-certinfo
chmod +x /usr/local/bin/cfssl /usr/local/bin/cfssljson /usr/local/bin/cfssl-certinfo

ls /usr/local/bin
# cfssl cfssl-certinfo cfssljson containerd ...

2. etcd 证书生成

所有证书的生成操作只在 master1 上做，然后 scp 到其他 master。

2.1 创建证书目录

1
2
mkdir -p /etc/etcd/ssl
mkdir -p /data/softs/pki && cd /data/softs/pki

需要的 11 个 JSON 配置文件（生产里通常从运维仓库分发）：

1
2
3
4
admin-csr.json           apiserver-csr.json      ca-config.json
ca-csr.json              etcd-ca-csr.json        etcd-csr.json
front-proxy-ca-csr.json  front-proxy-client-csr.json
kube-proxy-csr.json      manager-csr.json        scheduler-csr.json

2.2 生成 etcd CA 与证书

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
# 生成 CA 根证书
cfssl gencert -initca etcd-ca-csr.json | cfssljson -bare /etc/etcd/ssl/etcd-ca

# 生成 etcd server 证书（hostname 和 IP 必须包含所有 3 个节点）
cfssl gencert \
   -ca=/etc/etcd/ssl/etcd-ca.pem \
   -ca-key=/etc/etcd/ssl/etcd-ca-key.pem \
   -config=ca-config.json \
   -hostname=127.0.0.1,master1,master2,master3,<master1-ip>,<master2-ip>,<master3-ip> \
   -profile=kubernetes \
   etcd-csr.json | cfssljson -bare /etc/etcd/ssl/etcd

生成结果：

1
2
3
ls /etc/etcd/ssl/
# etcd-ca.csr  etcd-ca-key.pem  etcd-ca.pem
# etcd.csr     etcd-key.pem     etcd.pem

2.3 把证书复制到其他 master

1
2
3
4
5
6
for NODE in master2 master3; do
  ssh $NODE "mkdir -p /etc/etcd/ssl"
  for FILE in etcd-ca-key.pem etcd-ca.pem etcd-key.pem etcd.pem; do
    scp /etc/etcd/ssl/${FILE} $NODE:/etc/etcd/ssl/${FILE}
  done
done

内网 IP 用占位符 <master1-ip> 等替代；实际操作换成真实 IP。

3. etcd 二进制安装

1
2
3
4
5
6
7
8
9
cd /data/softs
tar -xf etcd-v3.5.11-linux-amd64.tar.gz
mv etcd-v3.5.11-linux-amd64/etcd /usr/local/bin/
mv etcd-v3.5.11-linux-amd64/etcdctl /usr/local/bin/
mv etcd-v3.5.11-linux-amd64/etcdutl /usr/local/bin/

etcdctl version
# etcdctl version: 3.5.11
# API version: 3.5

推送到 master2 / master3：

1
2
3
for NODE in master2 master3; do
  scp /usr/local/bin/etcd* $NODE:/usr/local/bin/
done

4. etcd 配置文件

4.1 etcd.config.yml（master1 示例）

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
name: 'master1'
data-dir: /var/lib/etcd
wal-dir: /var/lib/etcd/wal
snapshot-count: 5000
heartbeat-interval: 100
election-timeout: 1000
quota-backend-bytes: 0
listen-peer-urls: 'https://<master1-ip>:2380'
listen-client-urls: 'https://<master1-ip>:2379,http://127.0.0.1:2379'
max-snapshots: 3
max-wals: 5
initial-advertise-peer-urls: 'https://<master1-ip>:2380'
advertise-client-urls: 'https://<master1-ip>:2379'
initial-cluster: 'master1=https://<master1-ip>:2380,master2=https://<master2-ip>:2380,master3=https://<master3-ip>:2380'
initial-cluster-token: 'etcd-k8s-cluster'
initial-cluster-state: 'new'
strict-reconfig-check: false
enable-v2: true
enable-pprof: true
client-transport-security:
  cert-file: '/etc/etcd/ssl/etcd.pem'
  key-file: '/etc/etcd/ssl/etcd-key.pem'
  client-cert-auth: true
  trusted-ca-file: '/etc/etcd/ssl/etcd-ca.pem'
  auto-tls: true
peer-transport-security:
  cert-file: '/etc/etcd/ssl/etcd.pem'
  key-file: '/etc/etcd/ssl/etcd-key.pem'
  peer-client-cert-auth: true
  trusted-ca-file: '/etc/etcd/ssl/etcd-ca.pem'
  auto-tls: true

master2 / master3 的配置只需要改 name 字段、listen-peer-urls 里的 IP。

4.2 etcd.service 单元

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
[Unit]
Description=Etcd Service
Documentation=https://coreos.com/etcd/docs/latest/
After=network.target

[Service]
Type=notify
ExecStart=/usr/local/bin/etcd --config-file=/etc/etcd/etcd.config.yml
Restart=on-failure
RestartSec=10
LimitNOFILE=65536

[Install]
WantedBy=multi-user.target
Alias=etcd3.service

5. 启动与验证

5.1 启动

1
2
3
systemctl daemon-reload
systemctl enable --now etcd.service
systemctl status etcd.service

5.2 验证集群状态

1
2
3
4
5
6
7
export ETCDCTL_API=3

etcdctl --endpoints="<master1-ip>:2379,<master2-ip>:2379,<master3-ip>:2379" \
  --cacert=/etc/etcd/ssl/etcd-ca.pem \
  --cert=/etc/etcd/ssl/etcd.pem \
  --key=/etc/etcd/ssl/etcd-key.pem \
  endpoint status --write-out=table

预期输出：

1
2
3
4
5
6
7
+------------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+
|     ENDPOINT     |        ID        | VERSION | DB SIZE | IS LEADER | IS LEARNER | RAFT TERM | RAFT INDEX | RAFT APPLIED INDEX | ERRORS |
+------------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+
| <master1-ip>:2379 | b55511e3290daa2b |  3.5.11 |   20 kB |      true |      false |         2 |          8 |                  8 |        |
| <master2-ip>:2379 | 64aba84b878707bb |  3.5.11 |   20 kB |     false |      false |         2 |          8 |                  8 |        |
| <master3-ip>:2379 | 3eafefedb1462a99 |  3.5.11 |   20 kB |     false |      false |         2 |          8 |                  8 |        |
+------------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+

只要 IS LEADER 有一个 true，RAFT TERM 都一致，ERRORS 都为空，集群就是健康的。

5.3 etcd 性能压测

1
etcdctl check perf

5.4 备份与恢复

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
# 备份
etcdctl snapshot save /tmp/etcd-snapshot.db
etcdctl snapshot status /tmp/etcd-snapshot.db --write-out=table

# 恢复（停 etcd 后）
etcdctl snapshot restore /tmp/etcd-snapshot.db \
  --name master1 \
  --initial-cluster master1=https://...,master2=...,master3=... \
  --initial-advertise-peer-urls https://<master1-ip>:2380 \
  --data-dir /var/lib/etcd-restore

6. 排错速查

现象	原因	解决
`etcdctl: command not found`	旧版本客户端	`export ETCDCTL_API=3`
`certificate verify failed`	CA 不匹配	检查 `trusted-ca-file`
raft term 不增长	集群未选主	检查 `initial-cluster` 是否 3 节点都在
`db size exceeds quota`	默认 2GB	调大 `quota-backend-bytes`
peer URL 改后无法加入	老的 peer 还在	删 data-dir 重启

7. 小结

etcd 集群是 K8s 状态的"心脏"：

必须 3 节点或 5 节点（raft 多数派）
所有通信必须 TLS（peer + client 都要）
证书 hostname 列表必须包含所有 3 节点
定期备份（etcdctl snapshot save）

下一步：K8s 1.28 核心组件二进制部署：apiserver/scheduler/controller-manager。
