K8s API Server 高可用：Nginx 四层 + Keepalived VIP 漂移

写于 2021-03，背景：K8s 1.21 GA 阶段，二进制高可用部署仍然是国内大厂主流。本文用编译版 Nginx 1.24 + Keepalived 2.2 实现 API Server 的统一入口 VIP 漂移。

一、为什么需要 VIP

3 master 集群时，apiserver 监听在 3 个不同 IP:6443：

1
2
3
master1 → 192.168.139.133:6443
master2 → 192.168.139.134:6443
master3 → 192.168.139.135:6443

但 kubectl 只能配 1 个 --server：

1
2
kubectl --server=https://192.168.139.133:6443 get nodes
# 如果 master1 挂了？

解决思路：在 master 节点前再加一层"虚拟 IP"，3 个 master 通过 VRRP 协议竞选 VIP，VIP 永远在 1 个能用的 master 上。

1
2
3
4
5
kubectl → VIP:6443 (192.168.139.150)
              ↓ VRRP
     ┌────┴────┬────────┐
   master1   master2  master3
   :6443     :6443    :6443

二、方案选型

方案	优点	缺点
Nginx + Keepalived	成熟稳定，二层/四层都能做	需要编译
HAProxy + Keepalived	性能比 Nginx 高	配置稍复杂
Envoy + Keepalived	支持高级路由	太重
公有云 SLB	零运维	绑定云厂商

本文选 Nginx stream + Keepalived——最常见、配置清晰。

三、集群规划

主机名	IP	角色
master1	192.168.139.133	nginx + keepalived MASTER
master2	192.168.139.134	nginx + keepalived BACKUP
master3	192.168.139.135	nginx + keepalived BACKUP
VIP	192.168.139.150	漂移地址

端口约定：

apiserver：6443
nginx stream 监听：8443（外部访问 VIP:8443 → 内部 apiserver 6443）
keepalived VRRP：协议号 112

四、编译 Nginx（master1 + master2）

只在两台装 nginx + keepalived 即可（master3 不需要，节省资源）。如果所有 3 台都装，keepalived 仍能正常选举。

4.1 装编译依赖

1
apt install -y make g++ openssl libssl-dev libpcre3 libpcre3-dev zlib1g-dev libgd-dev

4.2 编译 Nginx

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
cd /k8s/softs
tar xf nginx-1.24.0.tar.gz && cd nginx-1.24.0

./configure \
  --prefix=/usr/local/nginx \
  --with-http_ssl_module \
  --with-http_stub_status_module \
  --with-pcre \
  --with-http_gzip_static_module \
  --with-stream \
  --with-stream_ssl_module

make -j$(nproc) && make install

关键参数：**--with-stream**（TCP 四层代理），**--with-stream_ssl_module**（与 apiserver HTTPS 通信）

4.3 Nginx 主配置

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
cat > /usr/local/nginx/conf/nginx.conf << 'EOF'
worker_processes  1;
events {
    worker_connections  1024;
}
http {
    include       mime.types;
    default_type  application/octet-stream;
    log_format  main  '$remote_addr - $remote_user [$time_local] "$request" '
                      '$status $body_bytes_sent "$http_referer" '
                      '"$http_user_agent" "$http_x_forwarded_for"';

    sendfile        on;
    keepalive_timeout  65;
    autoindex  on;
    gzip  on;
    gzip_buffers 32 4K;
    gzip_comp_level 6;
    gzip_min_length 1k;
    gzip_types application/javascript text/css text/xml;
    gzip_disable "MSIE [1-6]\.";
    gzip_http_version 1.1;
    gzip_vary on;

    client_body_buffer_size 1024k;
    client_max_body_size 2048m;

    client_header_buffer_size    128k;
    large_client_header_buffers  4  128k;

    proxy_buffer_size  256k;
    proxy_buffering  on;
    proxy_buffers 64 128k;
    proxy_busy_buffers_size 512k;

    include conf.d/*.conf;
}

stream {
    log_format proxy '[$time_local] $protocol status:$status, '
                     'client: $remote_addr, upstream:"$upstream_addr", '
                     'bytes: $bytes_sent/$bytes_received '
                     'time: $session_time/$upstream_connect_time';

    include stream/*.conf;
}
EOF

mkdir -p /usr/local/nginx/conf/{conf.d,stream}

4.4 stream 配置

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
cat > /usr/local/nginx/conf/stream/stream.conf << 'EOF'
upstream k8sapiserver {
    hash $remote_addr consistent;
    server 192.168.139.133:6443  max_fails=3 fail_timeout=30s;
    server 192.168.139.134:6443  max_fails=3 fail_timeout=30s;
    server 192.168.139.135:6443  max_fails=3 fail_timeout=30s;
}

server {
    error_log  logs/8443_error.log;
    access_log logs/8443_access.log proxy;
    listen 8443;
    proxy_connect_timeout 1s;
    proxy_pass k8sapiserver;
}
EOF

关键参数：

hash $remote_addr consistent：同一客户端始终连同一后端（会话保持）
max_fails=3 fail_timeout=30s：3 次失败标记 down，30 秒后重试
proxy_connect_timeout 1s：连不上后端立即失败，让 keepalived 切主

五、systemd 单元

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
[Unit]
Description=kube-apiserver nginx proxy
After=network.target network-online.target
Wants=network-online.target

[Service]
Type=forking
ExecStartPre=/usr/local/nginx/sbin/nginx -c /usr/local/nginx/conf/nginx.conf -p /usr/local/nginx -t
ExecStart=/usr/local/nginx/sbin/nginx -c /usr/local/nginx/conf/nginx.conf -p /usr/local/nginx
ExecReload=/bin/kill -s HUP $MAINPID
PrivateTmp=true
Restart=always
RestartSec=5
StartLimitInterval=0
LimitNOFILE=65536

[Install]
WantedBy=multi-user.target

启动：

1
2
3
4
systemctl daemon-reload
systemctl enable --now kube-nginx
systemctl status kube-nginx
curl 192.168.139.133:8443  # 不报错即可

六、Keepalived 配置

6.1 编译 Keepalived（master1 + master2）

1
2
3
4
5
cd /k8s/softs
tar xf keepalived-2.2.8.tar.gz && cd keepalived-2.2.8
./configure --prefix=/usr/local/keepalived
make -j$(nproc) && make install
mkdir -p /usr/local/keepalived/conf

6.2 健康检查脚本

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
cat > /usr/local/keepalived/conf/check_nginx.sh << 'EOF'
#!/bin/bash
A=$(ps -C nginx --no-header | wc -l)
if [ $A -eq 0 ]; then
    /usr/bin/systemctl start kube-nginx
    sleep 2
    if [ $(ps -C nginx --no-header | wc -l) -eq 0 ]; then
        /usr/bin/systemctl stop kube-keepalived
    fi
fi
EOF
chmod +x /usr/local/keepalived/conf/check_nginx.sh

逻辑：nginx 挂了 → 尝试重启 → 启不来就停 keepalived，让 VIP 漂到其他节点。

6.3 master1 配置（priority 100 = MASTER）

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
cat > /usr/local/keepalived/conf/kube-keepalived.conf << 'EOF'
global_defs {
    router_id LVS_DEVEL
}
vrrp_script check_nginx {
    script "/usr/local/keepalived/conf/check_nginx.sh"
    interval 5
    weight -5
    fall 2
    rise 1
}
vrrp_instance VI_1 {
    state MASTER
    interface ens33
    mcast_src_ip 192.168.139.133
    virtual_router_id 51
    priority 100
    nopreempt
    advert_int 2
    authentication {
        auth_type PASS
        auth_pass K8SHA_KA_AUTH
    }
    virtual_ipaddress {
        192.168.139.150
    }
    track_script {
        check_nginx
    }
}
EOF

6.4 master2 配置（priority 90 = BACKUP）

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
cat > /usr/local/keepalived/conf/kube-keepalived.conf << 'EOF'
global_defs {
    router_id LVS_DEVEL
}
vrrp_script check_nginx {
    script "/usr/local/keepalived/conf/check_nginx.sh"
    interval 5
    weight -5
    fall 2
    rise 1
}
vrrp_instance VI_1 {
    state BACKUP
    interface ens33
    mcast_src_ip 192.168.139.134
    virtual_router_id 51
    priority 90
    nopreempt
    advert_int 2
    authentication {
        auth_type PASS
        auth_pass K8SHA_KA_AUTH
    }
    virtual_ipaddress {
        192.168.139.150
    }
    track_script {
        check_nginx
    }
}
EOF

关键参数：

virtual_router_id 51：同一集群必须一致（不同集群必须不同！）
priority 100 > 90：数字大 = 高优先级
nopreempt：原 master 恢复后不抢回 VIP（避免脑裂）
track_script：nginx 挂了直接降 priority 5，触发 VIP 漂移
auth_pass K8SHA_KA_AUTH：明文 VRRP 认证，生产请用 16 位随机字符串

6.5 systemd 单元

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
[Unit]
Description=VRRP High Availability Monitor
After=network-online.target syslog.target
Wants=network-online.target
Documentation=https://keepalived.org/manpage.html

[Service]
Type=forking
KillMode=process
ExecStart=/usr/local/keepalived/sbin/keepalived -D -f /usr/local/keepalived/conf/kube-keepalived.conf
ExecReload=/bin/kill -HUP $MAINPID

[Install]
WantedBy=multi-user.target

启动：

1
2
3
4
systemctl daemon-reload
systemctl enable --now kube-keepalived
systemctl status kube-keepalived
journalctl -f -u kube-keepalived

七、验证

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
# master1 上看 VIP 是否绑定
ip addr show ens33
# inet 192.168.139.133/24 ...
# inet 192.168.139.150/32 ...  ← 看到这行说明 VIP 成功

# 验证 VIP 可访问 apiserver
curl -k https://192.168.139.150:8443/version
# {
#   "major": "1",
#   "gitVersion": "v1.28.5",
#   ...
# }

配置 kubectl 使用 VIP：

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
mkdir -p ~/.kube
cat > ~/.kube/config << EOF
apiVersion: v1
kind: Config
clusters:
- cluster:
    server: https://192.168.139.150:8443
    certificate-authority-data: <base64 编码的 ca.pem>
  name: kubernetes
contexts:
- context:
    cluster: kubernetes
    user: kubernetes-admin
  name: default
current-context: default
users:
- name: kubernetes-admin
  user:
    client-certificate-data: <base64 编码的 admin.pem>
    client-key-data: <base64 编码的 admin-key.pem>
EOF

kubectl get nodes

八、故障演练

8.1 模拟 master1 整机宕机

1
2
# 在 master1 上
shutdown -h now

观察 master2：

1
2
3
4
5
6
7
# master2 上
ip addr show ens33
# inet 192.168.139.134/24 ...
# inet 192.168.139.150/32 ...  ← VIP 漂到 master2

# 验证 VIP 仍可访问
curl -k https://192.168.139.150:8443/version

预期 5~10 秒后 VIP 漂到 master2，kubectl 无感。

8.2 模拟 master1 nginx 进程挂

1
2
# 在 master1 上
pkill nginx

观察：

check_nginx.sh 检测到 nginx 死 → 尝试 systemctl start kube-nginx
如果能起来：keepalived 继续，VIP 不漂
如果起不来（概率低）：脚本 systemctl stop kube-keepalived，VIP 强制漂走

8.3 恢复 master1

1
2
# master1
systemctl start kube-apiserver kube-nginx kube-keepalived

由于 nopreempt，VIP 不会抢回（继续在 master2）。这是有意设计——避免脑裂。

九、生产环境加固

关闭 mcast_src_ip 改 unicast（云环境 VRRP multicast 被禁用）：

1
2
3
4
5
6
7
vrrp_instance VI_1 {
    ...
    unicast_src_ip 192.168.139.133
    unicast_peer {
        192.168.139.134
    }
}

认证密码用随机 16 位：
1
openssl rand -base64 12
keepalived 配 3 台而不是 2 台：3 节点可以容忍 1 节点挂，2 节点只容忍 0 节点挂（脑裂风险大）。
监控 VIP：把 192.168.139.150 加入 Prometheus blackbox_exporter 监控。
DNS 解析：把 kubernetes-api.example.com 解析到 VIP，kubectl 用域名而不是 IP。

十、常见坑

virtual_router_id 不一致：3 节点 VRRP 选举失败
多播被防火墙挡：VRRP 协议号 112，iptables 默认会拦
nopreempt 没配：master1 恢复时把 VIP 抢回，可能导致短暂脑裂
check_nginx.sh 权限不足：keepalived 跑不了脚本，nginx 挂 VIP 不漂
VIP 绑定到错的 interface：interface ens33 配错网卡，VIP 上不去

十一、前置知识 / 下一步

前置：

nginx 编译与配置
keepalived VRRP 原理
kube-apiserver systemd 单元（参考 2020-12-15《K8s Master 三大组件》）

下一步：

K8s 集群插件（2021-09-15）—— CNI / CoreDNS / Metrics / Dashboard
K8s 集群管理（2021-12-15）—— 升级、节点隔离、排错
